The RT21 hand transmitter is available in a 1-channel or 2-channel version.

This variant features a transmitter-learns-transmitter (TLT) function, which allows the transmission codes to be transferred from one RT21 (TLT) to another RT21 (TLT). By transferring the transmission codes, both transmitters always trigger the same function in the receiver. Any number of transmitters can be coded the same way.

An easily visible LED lights up when the battery needs to be changed.

RT21E500xB00-K
Technical specifications
Coding Easywave
Frequency 868,30 MHz
Channels 1 or 2
Range typically 150 m in good free-field conditions
Power supply 1x 3V-battery, CR2032
Operating indicator LED
Operation transmission lasts as long as the button is pressed (maximum 36 seconds)
Operating temperature -20 °C to +60 °C
Dimensions (W/L/H) 36/55/16 mm
Weight 17 g (including battery)
Color anthracite similar to RAL 7016
Models
RT21E5001B00-K
1x PULSE

RT21E5002B00-K
2x PULSE
Scope of delivery
  • Hand transmitter including battery
  • Programming connector
  • Operating manual
Models
Product number Description
RT21E5001B00-K Hand transmitter, Easywave, 1x PULSE, transmitter learns transmitter, anthracite
RT21E5002B00-K Hand transmitter, Easywave, 2x PULSE, transmitter learns transmitter, anthracite
